CG Drives & Automation,01-5326-01r5 171
AnIn2 Advanced [516]
Same functions and submenus as under “AnIn1 Advan
[513]”.
Communication information
AnIn3 Function [517]
Parameter for setting the function of Analogue Input 3.
Same function as “AnIn1 Fc [511]”.
Communication information
AnIn3 Setup [518]
Same functions as “AnIn1 Setup [512]”.
Communication information
AnIn3 Advanced [519]
Same functions and submenus as under “AnIn1 Advan
[513]”.
Communication information
AnIn4 Function [51A]
Parameter for setting the function of Analogue Input 4.
Same function as “AnIn1 Fc [511].
Communication information
AnIn4 Set-up [51B]
Same functions as “AnIn1 Setup [512]”.
Communication information
516 AnIn2 Advan
Modbus Instance no/DeviceNet no:
43213–43220,
43542,
43552
Profibus slot/index
169/117–124,
170/191,
170/201
EtherCAT and CANopen index (hex)
4c8d - 4c94,
4dd6,
4de0
Profinet IO index
19597-19604,
19926,
19936
Fieldbus format
See [5131] - [5137].
Modbus format
517 AnIn3 Fc
Default: Off
Selection: Same as in menu [511]
Modbus Instance no/DeviceNet no: 43221
Profibus slot/index 169/125
EtherCAT and CANopen index (hex) 4c95
Profinet IO index 19605
Fieldbus format UInt
Modbus format UInt
518 AnIn3 Setup
Default: 4–20 mA
Dependent on Setting of switch S3
Selection: Same as in menu
[512].
Modbus Instance no/DeviceNet no: 43222
Profibus slot/index 169/126
EtherCAT and CANopen index (hex) 4c96
Profinet IO index 19606
Fieldbus format UInt
Modbus format UInt
519 AnIn3 Advan
Modbus Instance no/DeviceNet no:
43223–43230,
43543,
43553
Profibus slot/index
169/127–169/134,
170/192,
170/202
EtherCAT and CANopen index (hex)
4c97 - 4c9e,
4dd7,
4de1
Profinet IO index
19607-19614,
19927,
19937
Fieldbus format
See [5131] - [5137].
Modbus format
51A AnIn4 Fc
Default: Off
Selection: Same as in menu
[511]
Modbus Instance no/DeviceNet no: 43231
Profibus slot/index 169/135
EtherCAT and CANopen index (hex) 4c9f
Profinet IO index 19615
Fieldbus format UInt
Modbus format UInt
51B AnIn4 Setup
Default: 4-20 mA
Dependent on Setting of switch S4
Selection: Same as in menu
[512].
Modbus Instance no/DeviceNet no: 43232
Profibus slot/index 169/136
EtherCAT and CANopen index (hex) 4ca0
Profinet IO index 19616
Fieldbus format UInt
Modbus format UInt
