CG Emotron VFX48 Series User Manual

200 CG Drives & Automation, 01-5326-01r5
Communication information
Counter 1 Low value [6614]
Sets counter 1 low limit value. Counter 1 output (C1Q) is
de-activated (low) when the counter value is equal or smaller
than the low value.
Communication information
Counter 1 Decrement timer [6615]
Sets counter 1 automatic decrement timer value. The
counter 1 is decremented by 1 after elapsed decrement time
and if no new trigger has happened within the decrement
time. The decrement timer is reset to 0 at every counter 1
trig pulse
Communication information
Counter 1 Value [6619]
Parameter shows the actual value of counter 1.
Communication information
Counter 2 [662]
Refer to description for Counter 1 [661].
Counter 2 Trigger [6621]
Function is identical to Counter 1 Trigger [6611].
Communication information
Counter 2 Reset [6622]
Function is identical to Counter 1 Reset [6612].
Communication information
Modbus Instance no/DeviceNet no: 43573
Profibus slot/index 170/222
EtherCAT and CANopen index (hex) 4df5
Profinet IO index 19957
Fieldbus format Long, 1=1
Modbus format EInt
NOTE: Counter high value has priority so if high and
low values are equal then the counter output is de-
activated when the value is smaller than the low
value.
6614 C1 Low Val
Default: 0
Range: 0 - 10000
Modbus Instance no/DeviceNet no: 43574
Profibus slot/index 170/223
EtherCAT and CANopen index (hex) 4df6
Profinet IO index 19958
Fieldbus format Long, 1=1
Modbus format EInt
6615 C1 DecTimer
Default: Off
Off 0 Off
1 - 3600 1 - 3600 1 - 3600 s
Modbus Instance no/DeviceNet no: 43575
Profibus slot/index 170/224
EtherCAT and CANopenindex (hex) 4df7
Profinet IO index 19959
Fieldbus format Long, 1=1 s
Modbus format EInt
NOTE: Counter 1 value is common for all parameter
sets.
NOTE: The value is volatile and lost at power down.
6619 C1 Value
Default: 0
Range: 0 - 10000
Modbus Instance no/DeviceNet no: 42927
Profibus slot/index 168/86
EtherCAT and CANopen index (hex) 4b6f
Profinet IO index 19311
Fieldbus format UInt, 1=1
Modbus format UInt
6621 C2 Trig
Default: Off
Selection: Same selections as Digital Out 1 [541].
Modbus Instance no/DeviceNet no: 43581
Profibus slot/index 170/230
EtherCAT and CANopen index (hex) 4dfd
Profinet IO index 19965
Fieldbus format UInt
Modbus format UInt
6622 C2 Reset
Default: Off
Selection: Same selections as Digital Out 1 [541].
Modbus Instance no/DeviceNet no: 43582
Profibus slot/index 170/231
EtherCAT and CANopen index (hex) 4dfe
Profinet IO index 19966
Fieldbus format UInt
Modbus format UInt
