CG Emotron VFX48 Series User Manual

228 Options CG Drives & Automation, 01-5326-01r5
Table 46 Brake resistor VFX48 V types
Type
Rmin [ohm] if
supply 380–415
V
AC
Rmin [ohm] if
supply 440–480
V
AC
VFX48-003 43 50
-004 43 50
-006 43 50
-008 43 50
-010 43 50
-013 43 50
-018 43 50
-025 26 30
-026 26 30
-030 26 30
-031 26 30
-036 17 20
-037 17 20
-045 17 20
-046 17 20
-058 15.5 19
-060 10 12
-061 10 12
-072 10 12
-074 10 12
-088 7.5 9
-090 3.8 4.4
-105 6.5 8
-106 3.8 4.4
-109 3.8 4.4
-142 3.8 4.4
-146 3.8 4.4
-171 3.8 4.4
-175 3.8 4.4
-205 2.7 3.1
-210 2.7 3.1
-244 2.7 3.1
-250 2.7 3.1
-293 2.3 2.8
-295 2.3 2.8
-300 2 x 3.8 2 x 4.4
-365 1.8 2.2
-375 2 x 3.8 2 x 4.4
-430 2 x 2.7 2 x 3.1
-500 2 x 2.7 2 x 3.1
-600 3 x 2.7 3 x 3.1
-650 3 x 2.7 3 x 3.1
-750 3 x 2.7 3 x 3.1
-860 4 x 2.7 4 x 3.1
-1K0 4 x 2.7 4 x 3.1
-1K15 5 x 2.7 5 x 3.1
-1K25 5 x 2.7 5 x 3.1
-1K35 6 x 2.7 6 x 3.1
-1K5 6 x 2.7 6 x 3.1
-1K75 7 x 2.7 7 x 3.1
-2K0 8 x 2.7 8 x 3.1
-2K25 9 x 2.7 9 x 3.1
-2K5 10 x 2.7 10 x 3.1
Table 47 Brake resistor VFX52 V types
Type
Rmin [ohm] if
supply 440–480
V
AC
Rmin [ohm] if
supply 500–525
V
AC
VFX52-003 50 55
-004 50 55
-006 50 55
-008 50 55
-010 50 55
-013 50 55
-018 50 55
-026 30 32
-031 30 32
-037 20 22
-046 20 22
-061 12 14
-074 12 14
Table 48 Brake resistor VFX69 V types
Type
Rmin [ohm]
if supply
500–525
V
AC
Rmin [ohm]
if supply
550–600
V
AC
Rmin [ohm]
if supply
660–690
V
AC
VFX69-002 30.4 34.8 40.0
-003 30.4 34.8 40.0
-004 30.4 34.8 40.0
-005 30.4 34.8 40.0
-008 30.4 34.8 40.0
-010 30.4 34.8 40.0
-013 30.4 34.8 40.0
-018 30.4 34.8 40.0
-021 30.4 34.8 40.0
-025 30.4 34.8 40.0
-033 12.9 14.8 17.0
-042 12.9 14.8 17.0
-050 12.9 14.8 17.0
-058 12.9 14.8 17.0
-082 4.9 5.7 6.5
-090 4.9 5.7 6.5
-109 4.9 5.7 6.5
-146 4.9 5.7 6.5
-175 4.9 5.7 6.5
-200 4.9 5.7 6.5
-250 2 x 4.9 2 x 5.7 2 x 6.5
-300 2 x 4.9 2 x 5.7 2 x 6.5
-375 2 x 4.9 2 x 5.7 2 x 6.5
-400 2 x 4.9 2 x 5.7 2 x 6.5
-430 3 x 4.9 3 x 5.7 3 x 6.5
-500 3 x 4.9 3 x 5.7 3 x 6.5
-595 3 x 4.9 3 x 5.7 3 x 6.5
-650 4 x 4.9 4 x 5.7 4 x 6.5
-720 4 x 4.9 4 x 5.7 4 x 6.5
-800 4 x 4.9 4 x 5.7 4 x 6.5
-905 5 x 4.9 5 x 5.7 5 x 6.5
-995 5 x 4.9 5 x 5.7 5 x 6.5
-1K2 6 x 4.9 6 x 5.7 6 x 6.5
-1K4 7 x 4.9 7 x 5.7 7 x 6.5
