3-7 PC Health Status
By choosing the PC Health Status option from the CMOS Setup Utility menu (Figure
3-1), the screen below is displayed. This field shows you the current system
temperature/external voltages input and the current CPU FAN and System FAN
operating speed.
3-8 SeePU Setup
By choosing the Seepu Setup option from the CMOS Setup Utility menu (Figure
3-1), the screen below is displayed. This sample screen contains the manufacturer's
default values for the mainboard.
A. Clock By Slight Adjust
This field allows you to select a subtle speed of the CPU Front Side Bus for
overclocking posibility.
Figure 3-8 PC Health Status Screen
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
PC Health Status
: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Item Help
Menu Level
Shutdown Temperature
CPU VCore
+1.5V
+3.3V
+ 5 V
+ 12V
- 12V
- 5 V
5VSB(V)
Voltage Battery
Current CPU Temp.
Current SYSTEM FAN Speed.
Current CPU FAN Speed.
Disabled
1.75V
1.49V
3.32V
5.05V
12.18V
-11.98V
-5.02
2.49V
2.98V
48
o
C
4500 RPM
4500 RPM
System Memory Frequency
CPU Vcore Select
Auto Detect DIMM/PCI Clk
Spread Spectrum
Clock By Slight Adjust
CPU Clock Ratio
Auto
Default
Enabled
+/-0.5%
66
X 3
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
SeePU Setup
: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Item Help
Menu Level
Figure 3-9 SeePU Setup Screen
