3
F.058-B/MODEL 20/SEPT. 2000
SPECIFICATIONS
Cutting Dimensions
Cutting Width 20” (50.8 cm)
Minimum Cut* ½” (13 mm)
Clamp Opening 3¼” (8.3 cm)
Table Space
Front: 16” (41 cm)
Back: 20” (51 cm)
Machine Dimensions
Table Height 35” (89 cm)
Overall Height 47-1/2” (121 cm)
Overall Length 48-1/4” (123 cm)
Overall Width 35-1/2” (90 cm)
Net Weight (Approximate) 550 lbs (250 kg)
Shipping Weight (Approximate) 650 lbs (295 kg)
Electrical
Standard - 120 Volts (±10%)/12 Amps, 1 Phase, 60 Hz, AC. Service size 15 Amps
Optional - 220 Volts (±10%)/12 Amps, 1 Phase, 60 Hz, AC. Service size 15 Amps
Optional - 220 Volts (±10%)/12 Amps, 1 Phase, 50 Hz, AC. Service size 15 Amps
*With false clamp plate attached, minimum cut is 1-7/8” (48 mm).
**With table removed, can be fit through a 32” (81.3 cm) door opening.
Challenge reserves the right to make changes to any product or specification without notice and without
incurring responsibility to existing units.
NOTICE: UNSUPPORTED PRODUCT!
NO TECHNICAL SUPPORT AVAILABLE!
NO REPAIR PARTS AVAILABLE!
