17
Install the Door Control
1 Install the Door Control
To prevent possible SERIOUS INJURY or DEATH from electrocution:
l Be sure power is NOT connected BEFORE installing door control.
l Connect ONLY to 12 VOLT low voltage wires.
To prevent possible SERIOUS INJURY or DEATH from a closing garage door:
l Install door control within sight of garage door, out of reach of children at a
minimum height of 5 feet (1.5 m), and away from ALL moving parts of door.
l NEVER permit children to operate or play with door control push buttons or
remote control transmitters.
l Activate door ONLY when it can be seen clearly, is properly adjusted, and there
are no obstructions to door travel.
l ALWAYS keep garage door in sight until completely closed. NEVER permit
anyone to cross path of closing garage door.
INTRODUCTION
Compatible with MyQ
®
and Security+ 2.0™ accessories, see page 40. Your garage door
opener is compatible with up to 2 Smart Control Panels or 4 of any other Security+ 2.0™
door controls. NOTE:Older LiftMaster door controls and third party products are not
compatible.
Install the door control within sight of the door at a minimum height of 5 feet (1.5 m)
where small children cannot reach, and away from the moving parts of the door. For
gang box installations it is not necessary to drill holes or install the drywall anchors. Use
the existing holes in the gang box.
NOTE: Your product may look different than the illustrations.
1. Strip 1/4" (6 mm) of insulation from one end of the wire and separate the wires.
2. Connect one wire to each of the two screws on the back of the door control. The
wires can be connected to eitherS screw.
3. Mount the door control with the hardware provided.
