29
Adjustments
Introduction
Withouta properlyinstalled safetyreversal system, persons (particularlysmall children) could be
SERIOUSLY INJURED or KILLED by a closing garage door.
• Incorrect adjustment of garage door travel limits will interfere with proper operation of safety
reversal system.
• After ANY adjustments are made, the safetyreversal system MUST be tested.Door MUST reverse
on contactwith 1-1/2" (3.8 cm) high object (or 2x4 laid flat) on floor.
To prevent damage to vehicles, be sure fully open door provides adequate clearance.
Your garage door opener is designed with electronic controls to make setup and adjustments easy.The
adjustments allow you to program where the door will stop in the open (UP) and close (DOWN) position.
The electronic controls sense the amountofforce required to open and close the door. The force is
adjusted automatically when you program the travel.
If anything interferes with the door’s upward travel it will stop. Ifanything interferes with the door’s
downward travel,it will reverse.
One-Piece Doors Only
When setting the UP travel for a one-piece door ensure that the door doesnot slant backwardswhen
fully open (UP). Ifthe door is slanted backwards this will cause unnecessary bucking and/or jerking
when the door is opening or closing.
Programming Buttons
The programming buttonsare located on the leftside panel ofthe garage door opener and are used
to program the travel.
UP Button
Adjustment Button
DOWN Button
PROGRAMMING BUTTONS
To watch a short instructional video on how to program the travel on
your new garage door opener use your smartphone to read the QR
Code:
