Operation
Using the Smart Control Panel (continued)
Light Feature
The lights will turn on when someone entersthrough the open garage door and the safetyreversing
sensor infrared beam is broken. Ifusing the garage door opener light asa work light, turn the lighton
using the lightbutton on the wall control or the light will turn offifyou are beyond the range of the sensor.
LOCK
The LOCK feature is designed to preventactivation of the garage door opener from remote controls
while still allowing activation from the door control and keylessentry.This feature is useful for added
peace ofmind when the home is empty (i.e. vacation).
When the Lock feature is on, your remote controls have been disabled and a message will display on the
door control (Figure 1).
TIMER-TO-CLOSE (TTC)
DO NOT enable TTC if operating a one-piece door. TTC can be setto automatically close your garage
door from the fully open position after a specified period of time (1,5,10 minute intervalsor a custom
setting up to 99 minutes). The screen on the door control can display the statusof the TTC. Once the TTC
has been setand the door is open,the selected close interval will be displayed on the screen and toggle
between the time and TTC message. When the TTC is on, a message will display on the door control
screen (Figure 2).
To temporarily suspend the TTC feature press and release the HOLD button. Press REL button to
resume normal TTC operation (Figure 3).
BATTERY BACKUP
If your garage door opener has a battery backup one of two messageswill display on the door control if
there is a problem with the battery (Figures4 and 5).
Figure 2 Figure 3
Figure 1
Figure 4
Figure 5
SMARTCONTROLPANELMENU
The features on the door control can be programmed through a seriesofmenus on the screen and the
navigation buttons.
Navigation Buttons
Screen
Use the navigation buttons to make selections and program features.
The screen will display the time, temperature, and
current battery charge (if applicable) until the menu
button is pressed, and then it will display the menu
options. If there is a problem with the garage door
opener the screen will display the Diagnostic Code.
FEATURESMENU
Press the navigation button below “MENU” to view the Features menu.
Set the time, choose 12 or 24 hour clock and show/hide clock.
Set the Timer-to-Close feature off/on and set the time interval
before door closes.
Enable/disable lock.
Add remote controls, MyQ™ devices, an extra remote button
to control your garage door opener lights, or a keyless entry.
SETTINGS MENU
Press the navigation button below the down arrow till you see TEMPERATURE to view the Settings
menu.
Display the temperature in Fahrenheit or Celsius and
show/hide the temperature.
Select a language.
Set duration for garage door opener light to stay on after
operation, selectable range of 1-1/2 to 4-1/2 minutes. Turn the
Motion sensor off/on, and turn the entry light feature off/on.
Adjust the contrast of the screen.
