Chamberlain LA412 - REPAIR PARTS; CONTROL BOX; GATE OPERATOR ARM

46
1
2
3
4
5
REPAIR PARTS
CONTROL BOX
ITEM PART NUMBER DESCRIPTION
1 K74-36798-6 Standard Plastic Control Box Only
2 K94-36408-3 Reset Switch with Product ID
3 K94-36411 Piezo Alarm
4 K75-36635 Control Board Bracket
5 K1D8388-1CC Control Board
6 29-NP712 Battery
7 SOLPNL10W12V Solar Panel
NOT SHOWN
K74-36806-5 Metal Control Box Only
K94-36891 J15 Harness
K77-36541 Antenna
LA412CONTU Standard Plastic Control Box (with
control board)
GATE OPERATOR ARM
ITEM PART NUMBER DESCRIPTION
1 LA412DC Primary Arm
2 41ASWG-442SA Release Lever
3 41ASWG-0594SA Motor with Limit Switch Harness
4 41ASWG-0014SA Rear Connector
5 41ASWG-0597SA Cable 12 V with Connector
NOT SHOWN
41ASWG-0119 Release Key
K77-19130 Hardware Bag
Complete with: Gate bracket, post
bracket, pull-to-open bracket and
hardware
1
4
5
3
2
6
7
