32
Operation
Features
Your garage door opener is equipped with features to provide you with greater control over your garage
door operation.
MyQ
®
MyQ
®
technology usesa 900MHz signal to provide two-waycommunication between the garage door
opener and MyQ
®
enabled accessories.Your garage door opener is compatible with up to 8 MyQ
®
accessories.For Smartphone App control of your garage door opener and other MyQ
®
accessories,
Chamberlain's MyQ
®
Internet Gateway(model CIGBU) is required.
TIMER-TO-CLOSE (TTC)
The Timer-to-Close feature automaticallyclosesthe garage door after a specified time period. DO NOT
enable TTC if operating a one-piece door. TTC is to be used ONLY with sectional doors. Factory
default is set to off. The garage door opener will beep and the lights will flash before closing the door.
The TTC feature will deactivate if the garage door encounters an obstruction twice;or the safetyreversing
sensors are incorrectly installed.The garage door will reverse open and WILL NOT close until the
obstructions are clear or the safety reversing sensors are correctly installed.When the obstruction has
been cleared or the safetyreversing sensors have been aligned,the door will close when the garage
door opener is activated. TTC WILL NOT work if the garage door opener is operating bybattery power or
if the safetyreversing sensors are misaligned.This feature is NOT intended to be the primary method of
closing the door. A keyless entry should be installed in the event of an accidental lock out when
using this feature.
REMOTE CONTROLS AND DOOR CONTROLS (MyQ
®
)
Your garage door opener hasalready been programmed atthe factory to operate with your remote
control,which changes with each use,randomly accessing over 100 billion new codes. Compatible with
MyQ
®
enabled accessories,see page 40.
NOTE: Older Chamberlain remote controls, door controls, and third party products are not compatible.
MyQ
®
Accessories MEMORY CAPACITY
Remote Controls Up to 8
Door Controls Up to 2 MyQ
®
door controls
KeylessEntries Up to 1
THE PROTECTOR SYSTEM
®
(SAFETY REVERSING SENSORS)
When properly connected and aligned,the safetyreversing sensors will detect an obstruction in the path
of the infrared beam.Ifan obstruction breaksthe infrared beam while the door is closing, the door will
stop and reverse to full open position,and the opener lights will flash 10 times. Ifthe door is fully open,
and the safety reversing sensors are notinstalled, or are misaligned, the door will notclose from a
remote control. However,you can close the door if you hold the button on the door control or keyless
entry until the door isfullyclosed. The safety reversing sensors do not effect the opening cycle.
ENERGY CONSERVATION
For energyefficiencythe garage door opener will enter sleep mode when the door is fully closed. The
sleep mode shuts the garage door opener down until activated.The sleep mode is sequenced with the
garage door opener light bulb; as the light bulb turnsoff the sensor LEDswill turn off and whenever the
garage door opener lightsturn on the sensor LEDs will light. The garage door opener will not go into the
sleep mode until the garage door opener hascompleted 5 cycles upon power up.
LIGHTS
The garage door opener lightbulbs will turn on when the opener isinitially plugged in; power is restored
after interruption, or when the garage door opener is activated. The lights will turn off automaticallyafter
4-1/2 minutes.An incandescent A19 light bulb (100 watt maximum) or for maximum energyefficiencya
26W (100W equivalent) compactfluorescentlight (CFL) bulb may be used. NOTE: Do not use halogen,
short neck, or specialty light bulbs as these may overheat the end panel or light socket. Do not use LED
bulbs as they may reduce the range or performance of your remote controls.
NOTE: Do not use halogen, short neck, or specialty light bulbs as these may overheat the end panel or
light socket. Do not use LED bulbs as they may reduce the range or performance of your remote controls.
Light Feature
The garage door opener is equipped with an added feature;the lights will turn on when someone enters
through the open garage door and the safetyreversing sensor infrared beam is broken. For added
control over the light bulbs on your garage door opener, see page 33.
