1. With the door fully closed, check to ensure that the power lock
bolt is visible protruding through the track.
2. Press the button on the remote control to open the garage
door. The power door lock should retract before the door
begins to move.
3. Press the button on the remote control to close the garage
door. When the door reaches the fully closed position, the
power door lock should automatically activate to secure the
door.
NOTE: The power door lock can be manually released by
sliding the manual release handle to the open position.
However, if the power door lock does not function, contact
Chamberlain for a replacement.
8
OPEN THE DOOR MANUALLY:
1. Close the garage door. Slide the manual release handle
on power door lock to open before proceeding.
2. Pull down on the emergency release handle until you
hear a click.
3. Lift the door manually.
RECONNECT THE DOOR TO THE GARAGE DOOR
OPENER:
1. Pull down on the emergency release handle until you hear
a click. The door will reconnect on the next UP or DOWN
operation.
To prevent possible SERIOUS INJURY or DEATH from a falling
garage door:
• If possible, use emergency release handle to disengage door
ONLY when garage door is CLOSED. Weak or broken springs
or unbalanced door could result in an open door falling
rapidly and/or unexpectedly.
• NEVER use emergency release handle unless garage
doorway is clear of persons and obstructions.
Emergency
Release Handle
Adjustment
Power Door Lock
Manual Release
Lock Bolt
“Locked”
Power Door Lock
Manual Release
Lock Bolt
"Locked"
Test the Power Door Lock
Test the Emergency Release
