Champion D15 - Monitoring Menu Parameters

D10.D15.DRS15-MANS
Apr ‘19
- 35
-
V1.1 Output Frequency Hz Frequency to the motor
V1.2 Frequency Reference Hz
V1.3 Motor Speed rpm Calculated motor speed
V1.4 Motor Current A Measured motor current
V1.5 Motor Torque % Calculated motor shaft torque
V1.6 Motor Power % Calculated motor shaft power
V1.7 Motor Voltage V Calculated motor voltage
V1.8 DC Link Voltage V Measured DC link voltage
V1.9 Unit Temperature °F Heat sink temperature
V1.10 Motor Temperature % Calculated motor temperature
V1.11 Voltage Input V AI1
V1.12 Current Output mA AI2
V1.13 DIN1, DIN2, DIN3 Digital input statuses
V1.14 DIN4, DIN5, DIN6 Digital input statuses
V1.15 D01, R01, R02 Digital and relay output statuses
V1.16 Analogue Output mA A01
V1.17 Multimonitoring Items Displays three selectable monitoring values
Code Signal Name Unit Description
Variable Speed Drive (cont’d)
Monitoring Menu
The Monitoring Menu, accessible at the ‘Main Menu’ by pressing the ‘Main Menu Right’ button when ‘M1’ is visible
on the first line of the display, indicates the values for the various running parameters as in shown below.
