23 3/4"
SERVICE DOOR
REMOVABLE
AIR OUTLET
SAFETY VALVE
GUAGE &
DIRECT ONLINE START
CONTROLLER WITH
PRESSURE
BALL VALVE
3/4" NPT
LG SLOT
9/16" X 1"
MOUNTED
AIR DRYER WITH
2M (6FT) CORD,
SEPARATE 115V
POWER SUPPLY
REQUIRED
38 3/4"
77"
45"
62 5/8"
15 1/8"
MODEL
NO.
HP
PRESSURE
PSI
ACFM @ LOAD
PRESSURE
NOMINAL
SOUND @
1 METRE
FULL LOAD CURRENT (AMPS)
AIR
RECEIVER
GAL.
DRYER
FILTER
ELEMENT
WEIGHT
LBS
3-PHASE
200V 230V 460V
D10TD 10 125-145 33 65 dBA 32.2 28 14 120
ASD-40
115V, 60Hz,
5.24A
1
MICRON
970
D15TD 15 125-145 52 69 dBA 48.3 42 21 120
ASD-60
115V, 60Hz,
6.96A
1
MICRON
1175
INSTALLATION REQUIREMENTS
1. MAINTAIN 3 FEET DISTANCE FROM WALLS
AND OTHER OBJECTS FOR PURPOSE
OF COOLING AND SERVICING.
2. COMPRESSOR MUST BE LEVEL AND
ANCHORED DOWN TO SOLID LEVEL FLOOR.
3. AMBIENT CONDITIONS:
10ºC (50ºF) MIN. 40ºC (104ºF) MAX.
4. APPROACH TEMP. FROM TANK 5ºC (41ºF)
REMOVABLE
TOP PANEL
INSERTS
WITH 1/4" MOUNTING
DUCTIBLE EXHAUST
AIR OUTLET
REMOVABLE
SIDE PANEL
10 3/8"
26 1/2"
13 7/16"
12 3/8"
17 7/16"
ECN NO.
REVISION DESCRIPTION
DATE
REV.
1/1
LT
to change without notice.
DESCRIPTION OF DRAWING
DRAWING NO.
SHT NO
REV.
NAME OF PROJECT
DRAWN BY
CHECKED BY
DATE
SCALE
is continually trying to improve its products, specifications subject
WITH DRYER
DM 02/20/19 N.T.S
SALES-ENGINEERING DRAWING
D1015TD-SE
IMPORTANT NOTE: This print is the confidential property of
GARDNER DENVER, INC. It is not to be used or reproduced in any
manner, nor submitted to other parties for examination without the
prior approval of GARDNER DENVER, INC. GARDNER DENVER, INC.
D10-15TD SCREW COMPRESSOR
00
3/4" CONDUIT
OPENING
DRAIN
1/4" MANUAL
POWER IN
EMERGENCY
STOP
26 1/2"
WITH 1/4" MOUNTING
INSERTS
TUBE
6MM DRAIN
FILTER WITH
COALESCING
AIR INTAKE OPENING
REMOVABLE
REAR PANEL
5 1/4"
12 3/16"
13 3/16"
6 3/8"
