23 3/4"
INSTALLATION REQUIREMENTS
1. MAINTAIN 3 FEET DISTANCE FROM WALLS
AND OTHER OBJECTS FOR PURPOSE
OF COOLING AND SERVICING.
2. COMPRESSOR MUST BE LEVEL AND
ANCHORED DOWN TO SOLID LEVEL FLOOR.
3. AMBIENT CONDITIONS:
10ºC (50ºF) MIN. 40ºC (104ºF) MAX.
4. APPROACH TEMP. FROM TANK 5ºC (41ºF)
MODEL
NO.
HP
PRESSURE
PSI
ACFM @ LOAD PRESSURE
NOMINAL
SOUND @
1 METRE
VFD INPUT CURRENT RATING
(AMPS)
AIR
RECEIVER
GAL.
DRYER
FILTER
ELEMENT
WEIGHT
LBS
3-PHASE
MAX. CAP. MIN. CAP. 200V 230V 460V
DRS 15TD 15 135-145 51 21 69 61 48 23 120
ASD-60
115V, 60Hz,
6.96A
1
MICRON
1175
VOLTAGE PHASE
FUSE
TYPE
FUSE
AMP
DISCONNECT KIT NO.
(INC. FUSES & DISCONNECT)
200
3 HSJ
60 FD-060
230 50 FD-050
460 25 FD-025
6MM DRAIN
FILTER WITH
WITH 1/4" MOUNTING
TUBE
INSERTS
COALESCING
AIR INTAKE OPENING
REMOVABLE
REAR PANEL
5 1/4"
12 3/16"
13 3/16"
6 3/8"
DATEREV.
001/1
LT
DRS15TD-SE
REVISION DESCRIPTION
subject to change without notice.
DESCRIPTION OF DRAWING
DRAWING NO.
SHT NO
REV.
NAME OF PROJECT
DRAWN BY
CHECKED BY
DATE
SCALE
INC. is continually trying to improve its products, specifications
WITH DRYER
DM 02/20/19 N.T.S
SALES-ENGINEERING DRAWING
IMPORTANT NOTE: This print is the confidential property of
GARDNER DENVER, INC. It is not to be used or reproduced in any
manner, nor submitted to other parties for examination without
the prior approval of GARDNER DENVER, INC. GARDNER DENVER,
DRS 15TD SCREW COMPRESSOR
ECN NO.
INSERTS
WITH 1/4" MOUNTING
REMOVABLE
TOP PANEL
DUCTIBLE EXHAUST
AIR OUTLET
REMOVABLE
SIDE PANEL
13 7/16"
10 3/8"
26 1/2"
17 7/16"
12 3/8"
LG SLOT
CONTROLLER WITH
PRESSURE
AIR OUTLET
REMOVABLE
GUAGE &
SAFETY VALVE
SERVICE DOOR
9/16" X 1"
VARIABLE SPEED DRIVE
3/4" NPT
BALL VALVE
MOUNTED
AIR DRYER WITH
2M (6FT) CORD,
SEPARATE 115V
POWER SUPPLY
REQUIRED
38 3/4"
62 5/8"
77"
45"
15 1/8"
3/4" CONDUIT
OPENING
1/4" MANUAL
DRAIN
POWER IN
EMERGENCY
STOP
26 1/2"
