Chandler Systems D15 - Table of Contents

TABLE OF CONTENTS
Table of Contents................................................................................................................ 3
Valves Specications.......................................................................................................... 4
Legacy View Control Start Up Procedure.......................................................................... 5
Advance Settings.................................................................................................... 6
Status History ......................................................................................................... 9
Salt Monitoring Update......................................................................................... 10
Main Menu.......................................................................................................................... 15
Normal Operation................................................................................................................ 17
Master Programming Mode.............................................................................................. 19
Filter Master Programming................................................................................................ 21
Aeration Master Programming......................................................................................... 24
Cabinet Softener Breakdown............................................................................................. 27
Filter Breakdown................................................................................................................. 31
Aeration Breakdown............................................................................................................ 33
Side Valve Breakdown........................................................................................................ 36
Bypass Assembly............................................................................................................... 40
Service Instructions........................................................................................................... 41
Error Codes......................................................................................................................... 42
Troubleshooting................................................................................................................. 43
Valve Dimensions............................................................................................................... 44
Warranty............................................................................................................................. 46
One or more features of this product are covered by U.S. patents, visit http://csih2o.com/patents.php for more
information.
FCC Compliance Statement:
http://www.chandlersystemsinc.com/les/FCC_Compliance_Statement.pdf
Industry Canada Compliance Statement:
http://www.chandlersystemsinc.com/les/Industry_Canada_Compliance_Statement.pdf
WARNING:
Lubricants
Do NOT use Vaseline, oils, hydrocarbon lubricants or spray silicone anywhere! Petroleum base lubricants will
cause swelling of o-rings and seals. The use of other lubricants may attack plastic Noryl®. It is recommended
that Dow
Corning® silicone grease be used as a lubricant for all control valves. Dow Corning® 7 Release Compound is used
in the manufacture of Chandler Systems control valves. (Part # LT-150)
Sealants
Pipe dope and liquid thread sealers may contain a carrier that attacks some plastic materials. It is recommended
that only Teon® tape be used to seal plastic Noryl® threaded ttings.
