201-00-15 Suspension System-General Information
Diagnosis and Testing
Failure Table
Phenomena Possible Reasons Measures
•Swing / Derivation / Excursion
• Excessive difference of the kingpin
caster angle or camber angle of the
left and right wheels
• Perform tyre positioning. See the
section of Common Procedures for
relevant information.
• Toe-in value exceeds the regulated
scope.
• Perform tyre positioning. See the
section of Common Procedures for
relevant information.
• Abnormal automobile running
height (Front or rear, high or low)
• Inspect overload, loosened shock
absorbing spring or non-standard
spring.
• The steering mechanism or the ball
head of the tie rod is abraded.
• Inspect the steering system. See
Section 204-00 for relevant
information.
• Tyres are abraded or defective.
• Inspect the tyres. See Section
201-03 for relevant information.
• Heavy steering • Excessive kingpin caster angle
• Perform tyre positioning. See the
section of Common Procedures for
relevant information.
• Incorrect vehicle height (Front or
rear, high or low)
• Inspect overload, loosened shock
absorbing spring or non-standard
spring.
• The steering mechanism or the ball
head of the tie rod is abraded.
• Inspect the steering system. See
Section 204-00 for relevant
information.
• The ball head of the lower cross
arm is abraded.
• See the section of Maintenance
Procedures for relevant
information.
• Tyres are abraded or unblanced
• Inspect tyres. See Section 201-03
for relevant information.
• Lacking power steering force
• Inspect the steering system. See
Section 204-01 for relevant
information.
• Braking lagging • Different tyre pressure
• Fill gas into tyres at the precise
pressure. See Section 201-04 for
relevant information.
• Braking system failure
• Check the brake. See Section
203-00 for relevant information.
• Automobile Fluttering
• Unbalance and excessive wear of
the tyres
• Check the tyres. See Section
201-03 for relevant information.
• Abrasion of the driving axle of the
front wheels
• Check the driving axle of the front
wheels. See Section 202-01 for
relevant information.
•Abrasion of the steering system
•Check the steering system. See
Section 204-00 for relevant
information.
