201-00-16 Suspension System-General Information
Diagnosis and Testing (Continued)
Phenomena
Concrete Procedures/Results/Measures
Switch to fixed point inspection C.
No
Perform the Wheel alignment if necessary. Test
and operate the system to determine whether it is
in the normal condition.
Fixed Point Inspection C: Abnormal Running Trace
Phenomena
Concrete Procedures/Results/Measures
C1: Check the kingpin caster angle
1 Check the kingpin caster angle.
• Is the kingpin caster angle in regulated scope?
Yes
Switch to C2
No
Check the wear of the suspension components.
Replace or repair the abraded components if
necessary. See Sections 201-01 (former) and
201-02 (latter) for relevant information. Test and
operate the system to determine whether it is in
the normal condition.
C2: Check the rear suspension
1 Measure the distance between the left and right
wheels of the automobile
- Compare the measured value
• Are the data the same?
Yes
Switch to fixed point inspection D.
No
Check the wear of the rear suspension parts.
Replace or repair the abraded components if
necessary. See Section 201-02 for relevant
information. Test and operate the system to
determine whether it is in the normal condition.
Fixed Point Inspection D: Poor Running Comfort
Phenomenon
Concrete Procedures/Results/Measures
D1: Check the suspension assembly
1 Check the tyre air pressure.
- Automobile hoisting. See Section 100-01 for
relevant information.
- Check the leaked or damaged suspension
components.
• Are the suspension components leaked or
damaged?
Yes
Replace the suspension components if
necessary. See Sections 201-01 (former) and
201-02 (latter) for relevant information. Test
and operate the system to determine whether it
is in the normal condition.
No
