201-00-16 Suspension System-General Information
Diagnosis and Testing (Continued)
Phenomena
Concrete Procedures/Results/Measures
• Is the steering wheel in central position and the
wheel alignment data in regulated scope?
Yes
Switch to A4
No
Perform the wheel alignment if necessary. Test
and operate the system to determine whether it is
in the normal condition.
A4: Check the tyres
1 Check the excessive wear of the tyres
• Are the tyres excessively worn?
Yes
Replace the tyres. Test and operate the system to
determine whether it is in the normal condition.
No
Switch to A5
A5: Rotate wheels
1 Hoist the automobile. See Section 100-01 for
relevant information.
- Rotate wheels in a cross way.
• Does the automobile deviate?
Yes
Check the abrasion of the suspension parts.
Replace or repair the damaged parts if necessary.
See Section 201-01 for relevant information.
Test and operate the system to determine
whether it is in the normal condition.
No
Replace the tyres. Test and operate the system to
determine whether it is in the normal condition.
Fixed Point Inspection B: the steering wheel deviates from the central position
Phenomena
Concrete Procedures/Results/Measures
B1: Check the steering components
1 Hoist the automobile. See Section 100-01 for
relevant information.
- Check whether the steering components are
excessively worn.
• Are the steering components excessively worn?
Yes
Replace or repair the abraded components. See
Section 204-00 for relevant information.
No
Switch to B2
B2: Check the wheel alignment
1 Check the wheel alignment.
• Is the steering wheel in the central position and the
wheel alignment data in regulated scope?
Yes
