201-00-16 Suspension System-General Information
Diagnosis and Testing (Continued)
• Loosening of the front or rear
suspension components
• Repair or replace the suspension
components. See Section 201-01
for relevant information.
• Loosening or abrasion of the axle
bushing of the lower cross arm of
the front suspension
• Repair or replace the axle bushing
of the lower cross arm of the front
suspension. See Section 201-01 for
relevant information.
• Loosening or abrasion of the
suspension assembly
• Check the suspension assembly.
See sections 201-01 (former) and
201-02 (latter) for relevant
information.
Fixed Point Inspection
Fixed Point Inspection A: Left and Right Derivation
Phenomena
Concrete Procedures/Results/Measures
A1: Check the left and right derivation
Warning: In order to avoid the bodily injuries caused by uncontrolled operation, inspection shall be
carried out by two operators to maintain safe driving status. The appropriate control to the steering wheel
shall be maintained. Failing to comply with these instructions may cause bodily injuries.
Notes: Following conditions must be met when automobiles are evaluated.
1 Check the tyre air pressure
- Drive the automobile at the speed of 88 km/h (55
mph) on smooth road.
- Confirm that there is no crosswind or gale
when driving
- Run back and forth for two times.
- If the trace of the automobile deviates 12 feet
within 7 seconds, the automobile deviates.
• Does the automobile deviate?
Yes
Switch to A2
No
Switch to fixed point inspection B.
A2: Check the steering connection rod
1 Hoist the automobile. See Section 100-01 for
relevant information.
- Check whether the steering connection rod is
excessively worn.
• Is the steering connection rod excessively worn?
Yes
Replace or repair the damaged component. Test
and operate the system to determine whether it is
in the normal condition.
No
Switch to A3
A3: Check the wheel alignment
1 Check the wheel alignment
Benni Mini
