201-00-16 Suspension System-General Information
Diagnosis and Testing (Continued)
Phenomena
Concrete Procedures/Results/Measures
See component test part in this Section.
Check the ball head. Switch to G4
No
If necessary, replace the wheel hub and
bearings assembly. Test and run the system
to determine if it is normal.
G4: Check the rear wheel bearing
1 Check the rear wheel bearing.
- Hold the bottom and top of the wheel and
sway forcefully. Check if bearings excessively
loosen.
- Rotate the rear wheel. Check working status
of the rear wheel.
Does bearing loosen or have sound?
Yes
Switch to G5
No
Switch to G6
G5: Measure the axial clearance of the rear wheel bearing
1 Disassemble the rear wheel
- Install the dial gauge with the installing
bracket, and ensure it to abut against the rear
brake drum.
- Axially push and pull the wheel hub, and
check the axial clearance of the rear wheel
bearing.
Is axial clearance maintained in the specification
value?
Yes
Switch to G6
No
If necessary, replace the rear wheel bearing.
See Section 201-02 for relevant information.
Test and run the system to determine if it is
normal.
G6: Check the wheel/tyre run-out value in the automobile
1 Use the radial run-out table and measure radial
run-out of the wheel and the tyre in the
automobile, and the transverse and radial
run-out amount of the assembly is smaller than
1.14 mm.
• The measured value is in regulated scope.
Yes
Switch to G12
No
Switch to G7
