201-00-16 Suspension System-General Information
Diagnosis and Testing (Continued)
Replace the tyre. Checke the run-out of the new
wheel. If the new wheel is in the regulated
scope, search and mark the lowest point of the
wheel run-out. Install the wheels, to make the
highest point of the wheel run-out coordinate
with the lowest point of the wheel run-out. Make
them balanced. Test and run the system to
determine if it is normal.
G10: Radial run-out of the rear wheel hub and the wheel bolts
1 Measure the run-out of the flange surface of the
wheel hub (larger than 0.254 mm) and the
circumferential run-out of the wheel bolt (larger
than 0.08 mm)
• Is the measured value in the normal range?
Yes
Switch to G11
No
Replace the
rear wheel hub. See Section 204-2
for relevant information. Test and run the system
to determine if it is normal.
G11:Circumferential run-out of the front wheel hubs and the tyre bolts
1 Dismount the front wheels.
- Dismount the brake disc.
- Measure the circumferential radial run-out of
the tyre bolts (larger than 0.06mm)
• Is measured value in the normal scope?
Yes
Check the run-out of the brake disc. See Section
203-00 for relevant information. Test and run the
system to determine if it is normal.
No
Replace the wheel hub. See Section 201-01 for
relevant information. Test and run the system to
determine if it is normal.
G12: Wheel balancing
1 Perform the wheel balancing. Perform the road
test.
•
Can automobile vibration be felt?
Yes
See Section 100-04 for relevant information.
No
Confirm the failure customer described.
