202-01-9 Driving Axle 202-01-9
DISASSEMBLING AND INSTALLATION (Continued)
BENNI MINI
2. 2. The driving axle is installed on the wheel hub
bearing.
3. Note: The wheel hub fixing nut should be
reinstalled.
Note: The wheel hub fixing nut should not be locked
at this stage.
The wheel hub fixing nuts is installed.
4. The lower cross arm is installed in the steering
knuckle.
5. The wheel and tyre are installed. See Section
201-03 for relevant information.
6. The transmission oil level is checked. See Section
301-03 for manual transmission gear.
7.
Warning: The wheel hub retaining nuts
should be locked through the socket for
preventing it from being damaging.
The wheel hub fixing nut is secured, and the
locking pin is inserted. (the torque should be
200±10Nm)
