202-01-11 Driving Axle 202-01-11
DISASSEMBLING AND INSTALLATION (Continued)
BENNI MINI
Driving axle(right)
Use the special tool
puller（CA201-006）
General tool
Two-claw puller
Dismounting
1. Warning: The hexagonal socket wrench Is
used to prevent the piston rod from
rotating.
The fixing nuts on the front supporting
column assembly at left are loosened.
2. The wheels and tyres are dismounted. See Section
201-04 for relevant information.
3. Warning: The wheel hub fixing nuts are
loosened by using the socket.
1. The wheel hub nuts is loosened.
4. The front oscillating arm ball joint are taken out
from the steering knuckle.
To Next Page
