202-01-15 Driving Axle 202-01-15
DISASSEMBLING AND INSTALLATION
(continue)
BENNI MINI
6. Disassemble the triangular frame/ball-cage frame
and dust shield.
• Use the retaining ring caliper to take out the
retaining ring and pull out the three-ball-pin type
universal joint.
• Remove the dust shield.
Installation
1. Notes
Replace all the retaining rings and nips.
2.Notes: the chamfer should point to the driving
axle.
Install three-ball-pin/ball-cage type
universal joint assembly.
• Cover the dust shield.
• Install and fix the three-ball-pin type universal
joint.
