… separated flue-air ducting
This type of ducting allows to disengage exhaust ue gases both outside the building
and into single ue ducts.
Comburant air may be drawn in at a different site from where the ue terminal is lo-
cated.
The splitting kit consists of a ue duct adaptor (100/80) and of an air duct adaptor.
For the air duct adaptor t the screws and seals previously removed from the cap.
The restrictor must be removed in case you install separated ue and air duct termi-
nals.
The 90° bend allows to connect the boiler to ue-air ducting regardless of direction as it
can be rotated by 360°. It can moreover be used as a supplementary bend to be coupled
with the duct or with a 45° bend.
020130_0700
A 90° bend reduces the total duct length by 0.5 metre.
A 45° bend reduces the total duct length by 0.25 metre.
