Chappee initia+ DUO 3.33 HTE - Zone 2 Heating Parameters; DHW and Boiler Parameters; Maintenance and Burner Control Parameters

39
INSTALLER Section (en)
7698967.01 (1-01/18)
ZONE2 HEATING PARAMETERS (with accessory Expansion Unit)
P11 1000 *Operating mode (0= Frost Protection, 1=Timed, 3=T.comfort) °C 3
P12 1010 *Comfort room temperature °C 20
P13 1012 *Reduced room temperature °C 16
P14 1020 *“Kt” curve slope - 1,5
P15 1021 *“Kt” curve drift - 0
P16 1026 *“Kt” curve adaptation (0=off) - 1
P17 1040 Flow temperature setpoint (minimum value) °C 25
P18 1041 Flow temperature setpoint (maximum value) °C 80
P19 1042 *Enable modulating temperature if set = “---” (ow temp. setpoint if P63=0) °C 80
P20 1050 *Room inuence (“---” = disabled) % 50
P21 1134 *Opening/Closing speed of mix valve s 30
DHW PARAMETERS
P22 1620
Operating mode in DHW (with Remote Control)
- 20=always enabled, 1=according to hourly heating programme,
2= according to hourly DHW programme.
P23 1640
Anti-legionella function Disabled
- 0
0=disabled, 1=periodic (depending on P24)
P24 1641
Periodic anti-legionella function enable (only if P23 =1)
- 7
1=daily, 2..6=intervals of 2..6 days, 7=once a week
P25 1663 Circulation temperature setpoint (additional DHW pump) °C 45
P26 5470 Preheating time for DHW circuit (1=10’ -- 144=1440’) min 0
BOILER PARAMETERS
P27 2243 Minimum boiler off time min 3
P28 2217 Frost Protection setpoint °C 5
P29 2250 Pump post-circulation time min 3
P30 2441 Max. fan speed (heating) rpm xxx
P31 2455 Minimum boiler off differential °C 5
P32 2720 Not used (Do NOT change this parameter) - 0
P33 2721 Not used (Do NOT change this parameter) - 1
SOLAR PLANT PARAMETERS (with accessory Expansion Unit)
P34 3810 Temperature - on differential °C 8
P35 3811 Temperature - off differential °C 4
P36 3830 Pump start function (“---” = disabled) min ---
P37 3850 Solar panel manifold overheating protection (“---“ = disabled) °C ---
P38 5050 DHW boiler tank charging temperature max °C 65
P39 5051 Maximum temperature of storage tank °C 90
CONFIGURATION
P40 5700 Not used (Do NOT change this parameter) - ---
P41 5710 Zone 1 heating circuit (1=enabled) - 1
P42 5715 Zone 2 heating circuit (1=enabled) - 0
P43 5730 DHW sensor (1=Tank sensor, 2=Thermostat, 3=instantaneous sensor) 1
P44 5890 Not used (Do NOT change this parameter) - 39
P45 5931 *BX2 sensor input (rst auxiliary sensor – section 11) - 0
P46 5932 *BX3 sensor input (second auxiliary sensor – section 11) - 0
P47 5977 *Input H5 (multifunction input – 18=Room thermostat) - 18
P48 6020 *Conguration of accessory Expansion Unit - 0
P49 6024 Input EX21 module 1 (conguration of HC Safety Thermostat) - 0
P50 6046 Input H2 module 1 (multifunction input) - 0
P51 6097 Sensor type collector (1= NTC, 2= Pt 1000) - 2
P52 6110 Building time constant h 15
P53 6220 Software version - ---
P54 6600 LPB device address - 1
P55 6601 LPB segment address - 0
P56 6640 Clock time source - 0
MAINTENANCE
P57 7045 Time after maintenance month xxx
P58 6704 View/Hide secondary fault internal code (0=no) - 1
BURNER CONTROL
P59 9512 Required ignition speed rpm xxx
P60 9524 Required minimum operating speed (low speed) rpm xxx
P61 9529 Required maximum operating speed (high speed) rpm xxx
