On back of grill, place upper back panel between side panels and above lower back panel. Secure upper back panel,
in lower holes, using one
1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer on each side.
Do not fully tighten screws until side shelf installation is complete in later steps.
5
15
1/4-20x1½”
screw
7mm lock
washer
7mm flat
washer
Upper back panel
