If you have questions or need assistance
during assembly, please call 1-800-241-7548.
09/18/14 • G464-001-010801
463343015
Si tiene alguna pregunta o si Necesita
ayuda durante el Ensamblado, llámenos Al
1-800-241-7548
Serial number | Número de serie
Date purchased | Fecha de compra
See rating Label on grill for serial number.
El número de serie se encuentra en la etiqueta de
especificaciones de la parrilla.
3-Burner Gas Grill

Table of Contents

Questions and Answers

  • K
    kristen20Aug 15, 2025
    How to fix Char-Broil 463343015 Gas grill igniter when it doesn't spark?
    • E
      edwardrussellAug 15, 2025
      If no sparks appear at any electrodes when the Electronic Ignition Button is pressed and no noise can be heard from the spark module on your Char-Broil Gas grill, the battery may not be installed properly; install the battery, ensuring that the “+” and “–” connectors are oriented correctly, with “+” on the cap end. It could also be due to a dead battery; replace it with a new alkaline battery. Another cause might be that the button assembly isn't installed properly; unscrew the button cap assembly and reinstall it, making sure the threads are aligned and engaged fully. Finally, the spark module may be faulty, and you should replace the spark module assembly.
  • M
    Matthew KnightAug 18, 2025
    Why no spark on Char-Broil 463343015 Gas grill but I can hear the igniter?
    • M
      Michael CherryAug 18, 2025
      If no sparks appear at any electrodes when you press the Electronic Ignition Button, but you can hear noise from the spark module of your Char-Broil Gas grill, the output lead connections may not be connected. Remove and reconnect all output connections at the module and electrodes.
  • J
    josephtaylorAug 21, 2025
    How to fix one burner not lighting on Char-Broil 463343015 Gas grill?
    • A
      Angela PopeAug 21, 2025
      If one burner does not light from other burners on your Char-Broil Gas grill, it is possible that there is grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush.
  • C
    Christine MedinaAug 25, 2025
    Why does my Char-Broil 463343015 Gas grill flare up?
    • Z
      Zachary GuzmanAug 25, 2025
      Flare-ups on your Char-Broil Gas grill are often due to grease buildup. Clean the burners and the inside of the grill/firebox to resolve this. Also, excessive fat in the meat can cause flare-ups, so trim the fat before grilling. Finally, lower the cooking temperature if it's too high.
  • K
    Karen HarrisAug 28, 2025
    Why is the flame so low on my Char-Broil 463343015 Gas grill?
    • A
      Anthony ReynoldsAug 28, 2025
      A sudden drop in gas flow or low flame in your Char-Broil Gas grill can be due to several reasons. First, check if you are out of gas and refill the LP cylinder if needed. Second, the excess flow valve might have tripped. To fix this, turn off the knobs, wait 30 seconds, and light the grill. If the flames are still low, turn off the knobs and the LP cylinder valve, disconnect the regulator, reconnect it, perform a leak test, turn on the LP cylinder valve, wait 30 seconds, and then light the grill. Lastly, a vapor lock at the coupling nut/LP cylinder connection could be the cause. Turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
  • H
    Harold RobertsonAug 31, 2025
    What to do if flames blow out on Char-Broil 463343015?
    • F
      fernandezjeffreyAug 31, 2025
      If the flames on your Char-Broil Gas grill are blowing out, it could be due to high or gusting winds; turn the front of the grill to face the wind or increase the flame height by turning the gas valve to a higher position. It could also be that you are low on LP gas, so refill the LP cylinder. Another cause might be that the excess flow valve tripped; refer to the “Sudden drop in gas flow” section for the solution.
  • K
    Kimberly BridgesSep 4, 2025
    Why are sparks weak on my Char-Broil 463343015 Gas grill?
    • Z
      zolsonSep 4, 2025
      If sparks are present but not at all electrodes or not at full strength on your Char-Broil Gas grill, check the output lead connections and reconnect all output connections at the module and electrodes. Also, look for arcing to the grill away from the burner(s) in a dark location. A weak battery can be the cause, so replace it with a new alkaline battery. If the electrodes are wet, use a paper towel to remove moisture. Cracked or broken electrodes can also cause this issue, so replace them if necessary.
  • Z
    Zachary BaxterSep 7, 2025
    What causes a grease fire in my Char-Broil 463343015?
    • M
      melissa73Sep 7, 2025
      If you have a persistent grease fire in your Char-Broil Gas grill, turn the knobs to OFF and turn the gas off at the LP cylinder. Leave the lid in position and let the fire burn out. After the grill cools, remove and clean all parts, because the grease is trapped by food buildup around burner system.
  • B
    Benjamin CarpenterSep 12, 2025
    What is a flashback on a Char-Broil Gas grill?
    • A
      Amanda MitchellSep 12, 2025
      If you experience a flashback (fire in burner tube(s)) with your Char-Broil Gas grill, it’s likely that the burner and/or burner tubes are blocked. Turn the knobs to OFF and clean the burner and/or burner tubes. Refer to the burner cleaning section of the Use and Care guide for detailed instructions.

Summary

Installation Safety Precautions

USE AND CARE

LP Cylinder Removal, Transport and Storage

Instructions for safely removing, transporting, and storing LP cylinders for the grill.

LP Cylinder Requirements

Details specifications and requirements for LP cylinders used with the grill.

LP Gas Properties

Explains the characteristics and safety of Liquefied Petroleum Gas.

LP Cylinder Filling

Provides guidance on safe and proper procedures for filling LP cylinders.

LP Cylinder Exchange and Leak Testing

LP Cylinder Exchange and Leak Testing

Procedures for exchanging LP cylinders and performing leak tests for safety.

Connecting Regulator to LP Cylinder

Detailed steps for connecting the gas regulator to the LP cylinder.

Gas Connection Leak Testing and Safety Tips

Leak Testing Valves, Hose and Regulator

Procedure for testing gas connections to ensure no leaks before operation.

General Safety Tips

General advice and best practices for operating the grill safely and efficiently.

Ignitor Lighting Procedures

Sideburner Lighting

Specific instructions for igniting the sideburner using electronic or match methods.

Grill Checks and Maintenance

Burner Flame and Operation Checks

How to check burner flames, ignitor function, valve operation, and hose condition.

Proper Grill Shutdown and Storage

Steps for turning off the grill and storing it safely, including seasonal storage.

General Grill Cleaning Procedures

Burner Assembly Cleaning and Maintenance

Limited Warranty Information

Warranty Coverage Scope and Period

Outlines what parts are covered, for how long, and the type of defects included.

Warranty Exclusions and Limitations

Lists items not covered by the warranty and disclaims implied warranties and consequential damages.

Grilling Guide: Getting Started

Initial Grill Setup and First Use

Instructions for initial setup, preparing the grill, and first-time operation.

Using Lava Rock and Briquettes

Guidance on using lava rock or briquettes, and why they are not recommended.

Understanding Grill Temperature

Explanation of the grill's temperature gauge and factors affecting cooking temperature.

Grill Pre-Heating and Cooking Techniques

Advice on pre-heating the grill and an introduction to direct cooking methods.

Grilling Guide: Cooking Methods and Safety

Indirect and Rotisserie Cooking

Explains indirect cooking for slow cooking and rotisserie cooking for roasts and poultry.

Food Safety Guidelines

Essential steps to ensure food safety, including cleaning, separation, cooking, and refrigeration.

Safe Internal Meat Temperatures

Recommended minimum safe internal temperatures for various types of meat and poultry.

Grilling Guide: Tips & Tricks

Sauce and Marinade Application

Guidance on applying sauces and marinades during grilling for optimal flavor and minimal flare-ups.

Enhancing Smoke Flavor and Skewer Use

Tips for adding smoke flavor with wood chips and selecting appropriate skewers for grilling.

Proper Utensil Usage

Recommendations for using grilling utensils like tongs and spatulas to avoid flare-ups and maintain food quality.

Grilling Guide: Cleaning Your Grill

Importance of Grill Cleaning

Explains why regular cleaning is essential for preventing grill fires and maintaining performance.

Routine and General Cleaning Procedures

Step-by-step instructions for daily cleaning and detailed cleaning of plastic, porcelain, painted, and stainless steel parts.

Grill Storage and Critter Prevention

Guidance on storing the grill safely and preventing critter issues in venturi tubes.

Emergency Procedures

Gas Leak and Fire Emergencies

Describes common emergencies related to gas leaks and fires with corresponding solutions.

Troubleshooting Guide: Gas and Electrical Issues

Gas and Electrical Problems

Addresses problems related to gas flow, ignition system electrical faults, and wiring.

Troubleshooting Guide: Flame and Ignition Issues

Gas Flow and Flame Issues

Solutions for problems like low flame, flames blowing out, flare-ups, grease fires, and flashback.

Electronic Ignition Problems

Diagnoses and resolves issues with the electronic ignition system, including spark generation and battery.

Parts Diagram

Parts List

Unlisted and Hardware Components

Lists components not pictured in the main diagram and the hardware pack details.

Hardware List

Product Registration

Registration Methods and Instructions

Outlines online, text, and mail options for registering the grill, with required information.
