Char-Broil Quickset - V Bar and Side Shelf Installation

V Bar
8 • 463822004
5
Parts to assemble:
1 V Bar
A. Place V bar onto supports at each
end of grill bottom.
NOTE:
Ceramic briquets are not required.
6
Parts to assemble:
2 Side Shelf
8 Wing Screw or
Crown Screw
A. Place shelves onto legs.
B. Secure with four wing screws or crown screws per shelf.
Side Shelf
Qty. 8
Qty. 8
OR
