Regulator hose
3
Place lower back panel between side panels at rear of bottom shelf. Secure lower back panel to side panels
using two 1/4-20x1/2” screws on each side.
1/4-20x1/2” screw
Lower back panel
Magnet
4
Grill head
This step requires two people to lift and position grill head onto cart. Carefully lower the grill head onto the
cart, aligning slots at bottom of grill head with posts on cart side panels. Make sure the regulator hose is
hanging outside the cart. Grill head must face open side of cart.
14
