CHART CryoDoser FleX - Common Replacement Parts

21
SpecicationsProduct Manual - CryoDoser FleX
™
LN
2
Dosing System
Common Replacement Parts
Item Number Part Description Part Number
1 CryoDoser FleX Body 35000
2 Short Arm 35050
3 Long Arm 35051 / 35061
4 EDS Electric Actuator 35053
5 EASE Electric Actuator 35058
6 Long Arm Support 35060
7 CryoDoser FleX Body Mounting Bracket 35054
8 Vent Heater Assy 35056
8a 10W Vent Heater Cartridge 35055.03
9 Dosing Head Heater Assy 35055
9a 6W Dosing Head Heater Cartridge 35055.01
10 Inlet Valve Assy 35057
11 Inductive Prox. Sensor Assy (Timing) 35067.004
12 Photoelectric Sensor Assy (Container) 35067.003
13 Encoder Assy 35067.002
14 Control Box Assy CC 35065
14a Control Box Assy PP 35063
15 Interface Box Assy CC 35064
15a Interface Box Assy PP 35066
16 Doser Stand 119K
17 Doser Base 326A
18 Y-Pattern Valve S6OMYCD
19 123 Fill Hose 123.S
20 10 Micron Filter CR_108
21 AC Power Cord 410
22 Ethernet Cable 2840.122
23 DC Power Interconnect Cord 2840.108
24 PolyTube - Black 334
25 Thermopurge Assy 35062
26 30mm Inductive Proximity Sensor Assy 35067.005
27 Sensor Cable(s) 2840.112.01
28 Encoder Cable 2840.903.01
29 Vent Heater Cable 2840.113.01
30 Dosing Head Heater Cable 2840.113.02
31 EDS Electric Actuator Cable 2840.901.01
32 EASE Electric Actuator Cable 2840.902.01
