5. Standards and safety
Intelect HPL 7 and HPL 15 have been designed and built in compliance with
the following standards:
EN 60601-1
IEC 60601-2-22
EN 60601-1-2
EN 60601-1-6
EN 62366
EN 62304
IEC 60825-1
Intelect HPL 7 and HPL15 is a class IV laser and as such features a safety
interlock.
Through a special button (patient button) connected to the machine it
is possible to interrupt the treatment at any time.
Connection interlock
Intelect HPL 7 and HPL15 features an interlock connector, positioned
above the footswitch connector on the back of the machine.
This acts as a series contact for the footswitch and is connected to the
door switch fitted to the door of the treatment room. The connector
voltage is 12V dc.
5.1 Laser standards
5.2 Safety features
1 3
2
4 5
Limit
Limit Switch
