TROUBLESHOOTING
Intelect® RPW
72
ERRORS
Error
Code
Description
100 The Patient Card button was pressed, but no valid treatments
were found on the Patient Card.
101 The Save to Patient Card button was pressed, but there is no
Patient Card inserted.
102 The Save to Patient Card button was pressed, but the card that
is currently inserted in the Patient Data Card Port is not a valid
patient data card.
103 The Save to Patient Card button was pressed, but the card that
is currently inserted in the Patient Data Card Port is full.
104 The Save to Patient Card button was pressed, but there is
already a treatment by that name on the Patient Card.
105 No patient name was entered when the Save to Patient Card
button was pressed.
106 No protocol name was entered when attempting to save a
protocol.
107 The Retrieve Protocol button was pressed, but no user protocols
have been set up in the unit. Refer to page 51 for more
information about saving user protocols.
108 The protocol cannot be saved because the unit has the
maximum number of protocols already saved.
Error
Code
Description
109 The MMC is being accessed, but there is no MMC inserted into
the MMC port.
110 The user is attempting to update the unit's software, but the
MMC inserted into the MMC port is not a software update MMC.
111 There was an error encountered when attempting to update
the control board software.
112 There was an error encountered when attempting to update
the interface board software.
113 The treatment being accessed on the Patient Card is a traction
type of treatment.
114 The treatment being accessed on the Patient Card is an
electrotherapy type of treatment.
115 The treatment being accessed on the Patient Card is a
continuous passive motion (CPM) type of treatment.
116 The treatment being accessed on the Patient Card is a
shortwave diathermy type of treatment.
117 The treatment being accessed on the Patient Card is an
unknown type of treatment.
Error Codes and Descriptions
