1. PRESENTATION
Clamp multimeter F09 emphasises reliability and simplicity
of use to respond to the needs of power professionals:
■ A compact unit integrating the current sensor for intensity
measurements without breaking the test circuit
■ Outstanding ergonomic features, in particular:
- automatic or manual selection of the type of signal to be
measured, AC or DC,
- measurement of the RMS value of any signal (AC+DC),
- automatic selection of measurement calibre,
- programmable audio voltage indication: V-Live,
- “measurement range exceeded” indication,
- Backlighting of the digital display
- auto power off system,
- MIN - MAX – PEAK value recording function,
- correction of deviations in DC measurement (DC zero)
- automatic compensation of measurement cable
resistance (Ω zero).
■ Compliance with CEI electrical safety standards and CE
markings
■ Lightness and ruggedness for field use
With all new additional features:
■ “Inrush” function in particular for measurement of motor
starting currents.
■ Phase order indication function using “2-wire” technique -
PFISTERER Licence - (instead of 3-wire) capable of
determination through contact only, with no fastidious
connections.
2. DESCRIPTION
(see diagram in § 8 Appendix)
➀➀
➀➀
➀ Jaws
➁➁
➁➁
➁ 6-way rotary switch:
OFF Deactivation of the clamp, activation is ensured
by selection of other functions
V Measurement of DC and AC voltages (rms value)
Continuity measurement, by use of the yellow
resistance key and semi-conductor test
A Measurement of DC and AC voltages (rms value)
Measurement of active, reactive and apparent
W~ powers and power factor in single phase or
balanced 3 phases systems (by use of the yellow
key)
Selection of phase order indicator for 3- phase
system with or without neutral
