16000 Appliances Hardware
16000 Appliances Getting Started Guide|36
Item Component Description
5 USB Type-C
port
For a serial connection to the appliance.
6 RJ45 Console
port and
2 USB 3.0 ports
RJ45 port for a serial connection to the appliance.
The USB 3.0 ports are backwards compatible to USB 2.0.
7 LOM port LOM (Lights Out Management) port to connect to the LOM card.
Note- In 16000/16200 Base appliances, LOM is optional by default.
8 Management
and
Synchronization
ports
The top synchronization port synchronizes with cluster members or a High
Availability peer.
The bottom management port is for an Ethernet connection to a remote
management computer.
9 ESD grounding
point
When servicing the appliance, connect an ESD strap to this point.
10 2 Storage
devices
When monitoring the storage devices with the raid_diagnostic
command, DiskID 0 is the left storage device, and DiskID 1 is the right
storage device (numbered 1 and 2 on the appliance's chassis).
Note - 16000/16200 Base appliances are supplied with one storage device
by default.
11 Storage device
power LED
n Off - Storage device power is off
n On (Green) - Storage device power is on
12 Storage device
activity LED
n Off - No storage device activity
n On (Amber) - Storage device activity
13 4 Expansion
line cards
4 expansion slots.
The slots from left to right are assigned eth1-0X, eth2-0X, eth3-0X, and eth4-
0X in the OS.
14
15
QSFP28 port 1
QSFP28 port 2
10/25/40/100 GbE QSFP28 port assigned eth1 in the OS.
10/25/40/100 GbE QSFP28 port assigned eth2 in the OS.
n Link speed LED
l Off
l On (Blue) - 10/25/40 Gbit/s data rate is selected
l On (Green) - 100 Gbit/s data rate is selected
n Port activity LED
l Off - No activity
l On (Amber) - Link exists
l Blinking (Amber) - Activity
