Attaching the Appliance Rails to the Appliance
Page 18
This figure displays the assembled rail plate and appliance rail.
Attaching the Appliance Rails to the
Appliance
Attach the appliance rails to the sides of the appliance. The rail plates are positioned to connect
the appliance rails to the rear of the rack.
Note - The appliance rail screws have 8 mm heads.
