USER'S MANUAL, NP10, NP20, NG10 (ALL NEO SYSTEM MODELS)
CHECKPOINT SYSTEMS, INC. FOR EXTERNAL USE
Document No. 10071753 Rev. 02 Page 18 of 28
5.0 SPECIFICATIONS
5.1 Overall Size
NP10:
Height: 172.78cm [68.02in]
Width: 50.75cm [19.98in]
Depth (front to back): 7.62cm [3.00in]
NP20:
Height: 172.78cm [68.02in]
Width: 34.26cm [13.49in]
Depth (front to back): 7.62cm [3.00in]
NG10:
Height: 174.7 [68.78in]
Width: 50.76cm [19.98in]
Depth (front to back): 7.72cm [3.04in]
5.2 EAS Sensor
Mechanical Specs:
PCB Layers: 8
PCB Materials: FR4
Dimensions: L X W: 116mm X 170mm [4.567in X 6.693in]
Electrical Specs:
DC Input / Output: +24V (other voltages are available using GPIO and connectors)
Clock Speed: 100 MHz
Clock Speed: 12.000 MHz
Connector function (Number): Connector type
Power Input / Output (2): 3-Pin 3.5mm connector, keyed
Power Output to Upper Bay (1): 3-Pin 3.5mm connector, keyed
Power Output for expansion module (1): 3-Pin 3.5mm connector, keyed
RF Antenna outputs (2): 2-Pin 3.5mm connector, keyed
