USER'S MANUAL, NP10, NP20, NG10 (ALL NEO SYSTEM MODELS)
CHECKPOINT SYSTEMS, INC. FOR EXTERNAL USE
Document No. 10071753 Rev. 02 Page 22 of 28
5.8 LED Board
Mechanical specs:
PCB Layers: 2
PCB Materials: FR4
Dimensions:NP10 - 319.5mm X 12mm [12.58in X 0.47in]
NP20 - 156.0mm X 12mm [6.14in X 0.47in]
Features: 10 LEDs aligned in a row.
Each LED can illuminate in various colors, relying on 3 individual LEDs (Red, Green, and
Blue) inside each of the 10 PCB-mounted LEDs.
Electrical specs:
Connector port (1): 7-Pin Hirose connector
NP10 / NG10 contains: ^PCB,A1179 LED NP10 (10055944).
NP20 contains: ^PCB,A1178 LED NP20 (10084027).
Required Cable (available as a FS spare): ^CABLE ASSY,LED NEO (10056250)
Power input rating: 24V / 60mA
5.9 Hub Board
Mechanical specs:
PCB Layers: 7
PCB Materials: FR4
Dimensions: 120mm x 123mm (approximate outside dimensions) [4.72 x 4.82in]
Electrical Specs:
DC Power Input: +24V DC
Regulated Outputs: +12V DC (for RFID Reader)
Connector Types: USB Type A (1), USB Type B (1), RJ-45 (2), Power input (see below)
Power Connector Input: 3-Pin 3.5mm connector, keyed
Required Cable (comes with system):
2-Conductor w/SHLD +24V PWR Jumper Cable (CKP P/N 10065117)
