USER'S MANUAL, NP10, NP20, NG10 (ALL NEO SYSTEM MODELS)
CHECKPOINT SYSTEMS, INC. FOR EXTERNAL USE
Document No. 10071753 Rev. 02 Page 23 of 28
5.10 RFID Reader
Mechanical specs:
PCB Layers: 8
PCB Materials: FR4
Dimensions: 225.2mm x 170mm (approximate outside dimensions) [8.87 x 6.69in]
Electrical Specs:
DC Power Input: +12V DC
Regulated Outputs: N/A
RF (UHF) Antenna Outputs: 4 SMA Female
Other Connector Types: RJ-45 (1), RS-232 Serial port for "Service".
B2B connector (1): 2 x 8 Header PCB-mount (from Hub Board)
5.11 Environmental
All the internal electronics shall meet or surpass the listed environment specifications:
Operating Temperature: 0° to + 60° C
Non-Condensing Relative Humidity: 5% to 95%
