5.4 System Controller
Mechanical Specs:
Small PCB about the size of a credit card
Electrical Specs:
CPU: 64-Bit Processor
Memory: 1GB 1600MHz LPDDR3 memory; 16GB
Connector function (Number): Connector type
Data Interface to/ from LnS Board (1): Header 2 x 20 PCB mounted, Female socket
Power input: DC power supplied from the Light and Speaker board (thru 2 x 20 header pins)
USB serial interface: USB Type A ports (3). Typically at least 2 USB ports are in always in
use. These two uses are (1) Data from Lower Bay and (2) Bluetooth USB Dongle. The third
available USB port can be used for either WiFi or Cell Modem. *NG10 has WiFi from factory.
Audio output: Stereo output, bare leads are soldered to the PCB terminals to reduce space
Ethernet connector: Not in use (except for field service and/or MFG needs)
HDMI port: *not in use
5.5 Light and Speaker Board
Mechanical Specs:
PCB Layers: 4
PCB Materials: FR4
Dimensions: L X W: 56mm X 100mm [2.2in X 3.94in]
Electrical Specs:
DC Power Input: 24V DC
Regulated Outputs: 5V DC
Connector function (Number): Connector type:
Power Input (1): 2-Pin Euro Plug F connector (CKP P/N 7100784) included as part of PWR
cable assemblies (for lower to upper power NP10 uses 10045277; NP20 uses 10090050).
Data Interface to/ from controller (1): Header 2 x 20 pins, Male pins
Speaker 2-Pin mini jack (1): Hirose 2-Pin port, keyed
