RM23712 TPS
18
Non-Operating humidity range, non condension
3.1.4.2 Altitude Requirements
The power supply shall operate within all specified limits over Aop Altitude range. The change
pressure condition shall not harm the power supply and the operation within specified regulations
shall be assured.
The power supply shall withstand Altitude storage specified in Anon-OP without any damage.
Table 10.Altitude Requirements
Operating Altitude range.
Non- Operating Altitude range
3.2 Electrical Performance
3.2.1 AC power Input Specification
3.2.1.1 AC Inlet connector
The power supply shall incorporate an AC input connector complying to IEC 320 C-14 power inlet
connector specification. This inlet shall be rated for operation at 10A/250VAC.
3.2.1.2 Input voltage and frequency specification
The power supply shall operate within all specified limits over the following input range. Harmonic
distortions of up to 10% of the rated line voltage must not cause the power supply to go out of
specified limits.The power supply shall power off if the AC input is below VAClow_limit and shall
start (auto recover) if VACrecover is reached. Input of VAC below VACrecover shall not cause any
damage to the power supply, including the input fuse.
The power supply shall supply the full output power in the voltage range of 90VAC to 264VAC.
Table 11.Rated output power for each input voltage range
3.2.1.3 HVDC Input voltage
The power supply supports High Voltage Direct Current (HVDC) input. Allowed HVDC input range
as shown in below table. The power supply shall operate within all specified limits, when HVDC
input meet requirements defined in this chapter.
Table 12.HVDC input voltage range
