Chenbro RM23712 User Manual

RM23712 TPS
27
PSON#=Low
ON
PSON#=High or Open
OFF
PSON#=Low, PSKILL=Open
OFF
MIN
MAX
Logic level low (power supply ON)
0V
0.66V
Logic level high (power supply OFF)
2.64V
3.64V
Source current, V
pson
=low
4mA
Power up delay: T
pson on delay
5ms
400ms
PWOK delay: T
pson pwok
50ms
3.2.4.2 Power OK (PG or PWOK) Output Signal
PWOK is a power good signal and shall be pulled HIGH by the power supply to indicate that all
outputs are within regulation limits. When any output voltage falls below regulation limits, an internal
failure or when AC power has been removed for a time sufficiently long, so that power supply
operation is no longer guaranteed, PWOK will be de-asserted to a LOW state. The start of the
PWOK delay time shall inhibited as long as any power supply output is in current limit.
See Table 21.
Table 28.PWOK signal characteristics
Signal Type
Open collector/drain output from power supply.
Pull-up to +3.3V located in the power supply.
PWOK=High
Power Good
PWOK=Low
Power Not Good
MIN
MAX
Logic level low voltage, I
sink
=4mA
0V
0.66V
Logic level high voltage,
I
source
=200μA
2.64V
3.46V
Sink current, PWOK =low
4mA
Source current, PWOK =high
2mA
PWOK delay: T
pwok_on
100ms
1000ms
PWOK rise and fall time
100μsec
Power down delay: T
pwok_off
1ms
200ms
3.2.4.3 SMBAlert
#
(PSAlert) Output Signal Pin
This signal indicates that the power supply is experiencing a problem that the user should
investigate. This shall be asserted due to Critical events or Warning events. The signal shall
activate in the case of critical component temperature reached a warning threshold, general failure,
over-current, over-voltage, under-voltage, failed fan. This signal may also indicate the power supply
is reaching its end of life or is operating in an environment exceeding the specified limits.
This signal is to be asserted in parallel with LED turning solid amber or blinking amber/green.
