9.2 Temporarily switching a layer
To quickly output a key sequence configured to a
different layer, use the following keys:
By combining the keys, the values are added up.
Example: You are currently on layer 0 and want to
output a key sequence that is assigned to
programmable function key (PF) 1 on layer 3.
¾ Press the Alt, Shift and PF1 keys
simultaneously.
The key sequence saved to the third layer is
output.
9.3 Configuring keys from PF1 to PF24
1 Launch a text editor such as Notepad or Word
so that you can keep track of any input or output
on the monitor.
2 Select configuration mode by pressing the Prog
key.
The decimal point on the seven-segment display
flashes.
3 Press the PF key to be configured.
4 Enter the string/key combination.
5 Press another PF key that you would like to
configure.
6 Exit configuration mode by pressing the Prog
key.
The decimal point on the seven-segment display
is no longer illuminated.
Example: Assigning the text "Test" to the PF1
key
¾ Press the following keys in sequence: Prog,
PF1, T, E, S, T, Prog.
Key Function
Alt 1 layer higher
Shift 2 layers higher
Ctrl 4 layers higher
9.4 Deleting the memory content of a
PF key
1 Select configuration mode by pressing the Prog
key.
2 Press the configured key.
3 Exit configuration mode by pressing the Prog
key.
9.5 Deleting the memory content of a
layer
1 Press the Layer key.
The display starts to flash.
2 Select the layer you wish to delete using the
keys F1 to F10.
3 Select configuration mode by pressing the Prog
key.
The decimal point on the seven-segment display
flashes.
4 Simultaneously press the Ctrl, Alt and Del keys.
5 Exit configuration mode by pressing the Prog
key.
The decimal point on the seven-segment display
is no longer illuminated.
9.6 Setting the output delay
In order to modify the string output according to
type of computer or program, you can choose
between 12 different delay times.
Key Delay in msec
F1 0
F2 2
F3 4
F4 6
F5 8
F6 10
F7 20
F8 30
F9 50
