CHERUBINI A510073 - To A530058 Remote Control with 4 Independent Channels; To Button Connected to the Wired Switch

1
2
2
1
25
Command sequence example: Command sequence example:
1
2
2
1
ON 1-2 ON 1-2OFF 1-2 OFF 1-2
1 12 2
A530058 remote control with 4 independent channels Button connected to the wired switch
Each time the programmed button is pressed briey (<1 sec), outputs
1 and 2 are turned on and off, as indicated in the sequence:
• The rst time the button is pressed it turns on both outputs.
• The second time the button is pressed it turns off both outputs.
Each time the button is pressed briey (<1 sec), outputs 1 and 2 are
turned on and off, as indicated in the sequence.
• The rst time the button is pressed it turns on both outputs.
• The second time the button is pressed it turns off both outputs.
With the outputs switched on, each time the programmed button is
pressed long (>1 sec), outputs 1 and 2 both change in brightness: the
rst time they increase in intensity, the next time they decrease and
so on, alternating.
With the outputs switched on, each time the button is pressed long
(>1 sec), outputs 1 and 2 both change in brightness: the rst time
they increase in intensity, the next time they decrease and so on,
alternating.
GB
