CHERY A21 SERVICE MANUAL MECHANISM OF 2.0NALC ENGINE
17
2.1.3 Installation steps
The installing steps are reverse to those for
removal.
2.2 Replace camshaft, bearing bushings,
valve and valve oil seal.
2.2.1 Needed tools and auxiliary materials
Special tools for valve oil seal, engine
transmission oil, a set of sleeve tools, an
adjustable spanner, special tools for timing
and a set of Allen wrenches
2.2.2 Removal
1) Remove the dynamo belt (see “removal
of dynamo belt” for details).
2) Remove the timing belt (see
“replacement of engine timing belt and
timing calibration” for details).
3) Remove the cover of engine valve
chamber.
4) Clamp the timing special tool into
camshaft slot and fasten the bolt.
