CHERY A21 SERVICE MANUAL MECHANISM OF 2.0NALC ENGINE
18
5) Dismantle the belt pulley of air intake
and exhaust camshafts with torque
wrench.
6) Remove the back cover of timing belt.
7) Dismantle the bearing caps of air intake
and exhaust camshaft respectively and
put them down in the sequence.
Note: The second, third, fourth and fifth
camshaft bearing caps are marked with I1, I2,
I3, I4 (E1, E2, E3, E4), which stands for the
corresponding bearing cap of 1, 2, 3, 4
cylinder respectively. (“I” refers to intake
camshaft, “E” refers to exhaust camshaft).
Torque:
