 Drive till a DTC is detected when DTC Trigger is selected. If no
DTCs are detected, press ESC to exit recording.
39
Recording… 5/60
6
DTC_CNT 6
FUELSYS1 OL
FUELSYS2 N/A
LOAD_PCT(%) 0.0
ETC(℃) -40
z The number “x/x” to the upper right corner of the screen
indicates the maximum frames that can be recorded and the
number of recorded frames.
7) The scan tool keeps recording PID data until user presses ESC
button, selected memory location is full, or it completes recording.
A message prompting to playback data shows on the screen.
z If you wish to playback recorded data, press ENTER button; if
you do not wish to playback, press ESC button, or use
LEFT/RIGHT button to select NO and press ENTER button
to return to Record Data menu.
Record Data
Record Done!
Playback data?
YES NO
►SHRTFT1(%) 0.0
