Max. current A 19.6 18
Model PA270X3CS-4MU2 PA270X3CS-4MU2
Type (Rotary、piston 、scroll）
Rotary Rotary
Brand
TOSHIBA TOSHIBA
Capacity W 7180/7210 6650
Power input W 2430/2540 2270
Starting
current---(LRA)locked-rotor
current
LRA
A
61/63
Running current
RLA
A
11.04/11.54 10.32
protector type （internal
/external）
internal internal
capacity uF-V 50-400 50/400
Compressor
Refrigeration lubricating oils,oil
charge
ml
Model YDK-32-4 YDK-30-4
Power input W 80 63
capacity uF 3.5 2
Fan motor
Indoor Fan Speed RPM
(High/Med/Low)
r/min
H：1300±30 rpm
M：1220±30 rpm
L：1150±30 rpm
1350/1200/1050
Indoor fan dia.*length mm φ107.5×799
Rows*Tubes*Circuits 2*18* 2*17*
Tube pitch* row pitch*Fin
spacing
mm
17.6*13*1.35 21*12.7*1.6
Tube outside dia.and typ mm
φ7internal threaded
pipe
φ7internal threaded pipe
Coil length x height x width mm
797*212*26
766*106*26
875*357*25.4
indoor unit
Indoor Air Circulation (High/Med/Low)
(actual/label)
m3/h
950 1050
