Chigo CS-25V3A-MA114A User Manual

7
7. Wire stripper (1 pc)
8. Sharp nose pliers and cutting pliers (1 pc for
each)
Cutting pliers: 150mm
9. Pipe bender (1 set)
10. Pipe expander (1 set)
For the expanding the opening of
the added pipe
11. Pipe cutter (1 pc)
For cutting the excess copper tube)
12. Reamer (1 pc)
For deburring the copper tube
13. File (1 pc)
150 or 200mm
14. Multimeter (1 set)
Level 5.0
15. Leakage detector or soap / sponge (1 pc)
For detecting if there is leakage at
the connection
16. Thermometer or digital temperature meter (1
pc)
For measuring the temperature of
the intake and outlet air of the air
conditioner
17. Pressure gauge
For measuring the working
pressure of the air conditioner
system
18. Level gauge or plummet (1 pc)
19. Putty scraper (1 pc)
20. Hex wrench (1 set)
21. Electric probe
22. Safety belt
23. Rope (acc. to weight-bearing requirements)
24. Laying cloth, cover cloth, shoe covers,
wiping cloth
25. Ladder and other requisite tools
Other auxiliary materials (depending on the site conditions)
Materials
1. Fixing support for outdoor unit
GB/T5059GB/T5213
2. Expansion bolt 10mm (4 pcs)
3. Anchoring bolt (Ø10mm) (with spring
washer) (4 pcs)
4. Concrete nail
5. Heat insulation strap
6. Insulation tape
7. Gypsum powder (1 bag)
8. Copper tube and power cable
9, PVC pipe (optional)
10. Square channel (optional)
For fixing the connection pipes
and wires
11. Others
