Item R Ref Description Qty Item ef Description Qty
1 1E49F01011 Screw M5×20 8 13 1E49F06002 Manifold 1
2 1E49FA07002 Oil Tank-Left 1 14 1E49F06005 Hose clip 1
3 1E49F07010 Pin 2 15 1E4907006-01 O-ring 1
4 1E49F07009A Rubber mount 2 16 1E49F07006 Oil Tank Cap 1
5 1E49FA06005 Choke lever 1 17 1E49F07015 Washer 1
6 1E49F06003 Air hose 1 18 1E49F07014 Tank vent 1
7 1E49F06001 Carburetor 1 19 1E49FA07003 Gasket 1
8 1E49F07020 Screw M5×65 2 20 1E49F07012 Oil Pick-up Filter 1
9 1E49F07011 Split pin 2 21 1E49F07005 Hose 1
10 1E49FA07001 Oil Tank-Right 1 22 1E49F07007 “U”-Rubber tube 1
11 1E49F07004
Connecting
Hose
1 23 1E49FA06002 Screw bracket 1
12 1E49F06006 Sleeve 1 24 1E49FA06001 Screw M4×5 1
50
To Next Page
